Description
Quality is not a matter of size or budget. This impressively demonstrates our smallest speaker model, the passive CCM5-P. The CCM5-P is a true high-performance speaker whose centerpiece is a heavy-duty 13 centimeter large coaxial driver, provenient from the area of professional PA technology. The genes of this advanced coax driver not only care for an amazingly great acoustic bandwidth, but also provide an efficiency of 88 dB (1 watt/1 meter).
The effectiveness of the CCM5-P therefore allows for the combination with lower output power amplifiers. For this reason, the smallest passive speaker from AiA is our top recommendation when it comes to the realization of smaller 3D home theaters operating with Dolby Atmos, Auro 3D or DTS:X.
Another major advantage of the CCM5-P is its small depth of only 75 mm. This makes it the perfect choice for in-wall as well as on-wall assembly.
SPECIFICATIONS
| Speaker type | Time-coherent 5,25“ Coax One Point Source |
| Principle | Vented |
| SPL | 105dB Cont. / 108dB Peak |
| Frequency range | 85Hz to 20kHz (-3 dB) |
| Sensitivity | 88dB / 1W |
| Power rating / Impedance | 100W / 8 Ω |
| Width x Height x Depth | 240 x 360 x 75mm |
| Weight | 4kg |
